3/8" Zinc-Alloy 24V AC Solenoid Valve with NBR Seal

$21.99
In stock
SKU
JFZSV00012

Our company utilizes cutting-edge technologies to produce high-quality valves at competitive prices. Introducing the ZSV Series Zinc-alloy Solenoid Valves, an exceptional solution for a variety of applications.

The ZSV series features a durable zinc alloy valve body that provides robust pressure resistance, while being more cost-effective compared to brass or stainless steel alternatives. Key specifications include:

  • Pipe Size: 3/8"
  • Flow Aperture: 4 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBRO
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: AC 24V
  • Power rating: 22 VA
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational pressure range: Air/Water: 0-8 Bar (0 to 116 PSI); Oil: 0-5 Bar (0 to 72 PSI)
  • Flow value: 0.6 Cv
  • Temperature Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: This solenoid valve is not designed for continuous operation and should not be used at a 100% duty cycle. While energized, the valve may become hot with a maximum coil temperature of about 176°F (80℃), meeting national standards (JB/T7352-2010). Continuous energization beyond 8 hours may lead to coil burnout.
