Zinc-Alloy 110V AC Solenoid Valve with NBR Seal - 3/8" Size

$21.99
In stock
SKU
JFZSV00010
Solenoid Valve Product Description

Discover top-quality solenoid valves crafted with the latest technologies at an affordable price. The Zinc-alloy Solenoid Valves from our USS-ZSV Series are designed to excel in a variety of applications.

  • Specifications:
    • Pipe Size: 3/8"
    • Flow Aperture: 4 mm
    • Body Material: Zinc Alloy
    • Gasket / Diaphragm / Seal: NBRO
    • Operation Type: Direct Lift Valve
    • Operation Mode: Normally Closed
    • Voltage: AC 110V
    • Power rating: 22 VA
    • Suitable Media: Water, oil, Diesel fuel, kerosene etc.
    • Operational pressure range:
      • Air/Water: 0-8 Bar (0 to 116 PSI)
      • Oil: 0-5 Bar (0 to 72 PSI)
    • Flow value: 0.6 Cv
    • Temperature Minimum: 14°F (-10°C)
    • Temperature Maximum: 176°F (80°C)
    • OVERHEATING WARNING: Not suitable for continuous operation (not a 100% duty cycle). During normal use, the solenoid valve may become hot, with the coil reaching a maximum temperature of about 176°F (80°C), in accordance with national standard: JB/T7352-2010. Prolonged energization for over 8 hours may cause the coil to burn.
