1/2" Zinc-Alloy 24V AC Solenoid Valve with NBR Seal

$24.99
In stock
SKU
JFZSV00013

With the utilization of cutting-edge technologies, we bring you high-quality solenoid valves at a budget-friendly price. The Zinc-alloy Solenoid Valves from our ZSV Series will prove to be a reliable tool for various applications.

Our ZSV solenoid valves boast a durable zinc alloy valve body that provides ample pressure resistance, all while being a cost-effective alternative to brass or stainless steel bodies.

Specifications:

  • Pipe Size: 1/2"
  • Flow Aperture: 16 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBR
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: AC 24V
  • Power rating: 22 VA
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational pressure range: Air/Water: 0-8 Bar (0 to 116 PSI); Oil: 0-5 Bar (0 to 72 PSI)
  • Flow value: 4.8 Cv
  • Temperature Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: Not designed for continuous operation (not a 100% duty cycle). During normal use, the solenoid valve may become hot while energized, with the coil reaching a maximum temperature of about 176°F (80℃). This temperature level is in full compliance with national standard: JB/T7352-2010. Continuous energization for over 8 hours may result in coil burnout.
