1/2" Zinc Alloy 110V AC Solenoid Valve with NBR Seal

$24.99
In stock
SKU
JFZSV00004

Discover the latest technologies and top-quality valves at competitive prices. Introducing the Zinc-alloy Solenoid Valves from our USS-ZSV Series. These solenoid valves are designed to be your go-to tool for a variety of applications.

The USS-ZSV solenoid valves come with a durable zinc alloy valve body that provides reliable pressure resistance while being cost-effective compared to brass or stainless steel bodies. Specifications include:

  • Pipe Size: 1/2"
  • Flow Aperture: 16 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBRO
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: AC 110V
  • Power rating: 22 VA
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational pressure range: Air/Water: 0-8 Bar (0 to 116 PSI); Oil: 0-5 Bar(0 to 72 PSI)
  • Flow value: 4.8 Cv
  • Temperature, Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: This solenoid valve is not designed for continuous operation and does not have a 100% duty cycle. Under normal operating conditions, the solenoid valve will heat up. The coil's maximum temperature is about 176°F (80℃), meeting the national standard: JB/T7352-2010. Continuous energization for more than 8 hours may cause the coil to burn.
