1/2" Zinc Alloy 12V DC Solenoid Valve with NBR Seal

$24.99
In stock
SKU
JFZSV00001

Discover a range of cutting-edge solenoid valves designed for top-notch performance at a competitive price. The Zinc-alloy Solenoid Valves from our USS-ZSV Series are the perfect solution for your applications.

Featuring a durable zinc alloy valve body, the USS-ZSV solenoid valves offer exceptional pressure resistance while being a cost-effective alternative to brass or stainless steel bodies. Here are the specifications:

  • Pipe Size: 1/2"
  • Flow Aperture: 16 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBRO
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: DC 12V
  • Power rating: 20 W
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational pressure range:
    • Air/Water: 0-8 Bar (0 to 116 PSI)
    • Oil: 0-5 Bar (0 to 72 PSI)
  • Flow value: 4.8 Cv
  • Temperature, Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature, Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: These solenoid valves are not designed for continuous operation (not a 100% duty cycle). While energized, under normal operating conditions, the solenoid valve will generate heat. The coil will reach a maximum temperature of about 176°F (80℃), which complies with national standard JB/T7352-2010. Continuous energization for more than 8 hours may cause the coil to burn.
