3/4" Zinc Alloy 110V AC Solenoid Valve with NBR Seal - Premium Quality

$27.99
In stock
SKU
JFZSV00005

Our company produces top-quality solenoid valves utilizing the latest technologies, offering premium products at competitive prices. The Zinc-alloy Solenoid Valves from our USS-ZSV Series are designed to excel in a wide range of applications.

The USS-ZSV solenoid valves are constructed with a zinc alloy valve body, providing a cost-effective alternative to brass or stainless steel while maintaining excellent pressure resistance. Specifications include:

  • Pipe Size: 3/4"
  • Flow Aperture: 20 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBRO
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: AC 110V
  • Power rating: 22 VA
  • Suitable Media: Water, oil, Diesel fuel, kerosene etc.
  • Operational pressure range:
    • Air/Water: 0-8 Bar (0 to 116 PSI)
    • Oil: 0-5 Bar (0 to 72 PSI)
  • Flow value: 7.6 Cv
  • Temperature, Minimum: 14°F (-10°C)
  • Temperature Maximum: 176°F (80°C)

NOTE: This solenoid valve is not meant for continuous operation and is not a 100% duty cycle. During normal operation, the solenoid valve may become hot, with the coil reaching a maximum temperature of 176°F (80°C), in compliance with national standards. Extended energization exceeding 8 hours may result in coil burnout.
