1 Inch Zinc-Alloy 110V AC Solenoid Valve with NBR Seal

$33.99
In stock
SKU
JFZSV00006

Discover top-quality valves crafted with the latest technologies, all offered at a reasonable price. The Zinc-alloy Solenoid Valves from our USS-ZSV Series are designed to be your go-to solution for various applications.

Our solenoid valves feature a durable zinc alloy valve body that provides ample pressure resistance at a lower cost compared to brass or stainless steel alternatives.

Specifications:

  • Pipe Size: 1"
  • Flow Aperture: 25 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBRO
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: AC 110V
  • Power rating: 22 VA
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational pressure range:
    • Air/Water: 0-8 Bar (0 to 116 PSI)
    • Oil: 0-5 Bar (0 to 72 PSI)
  • Flow value: 12.0 Cv
  • Temperature Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: These solenoid valves are not designed for continuous operation (not a 100% duty cycle). During normal use, the coil may get hot, with a maximum temperature of about 176°F (80℃) in compliance with the national standard: JB/T7352-2010. Prolonged energization beyond 8 hours may result in coil burnout.
