15 KW High Frequency Induction Heater 30-80 KHz, 16:1 Turns Ratio, 220V or 110V
$1,099.00
In stock
SKU
JFHFIH00001
Induction Heater
When it comes to inductive heating, the High-Frequency Induction Heater is among the best. It adopts the latest MOSFET and IGBT power units and the latest frequency control methods and techniques, providing high efficiency, low energy consumption, and very high output power. This enables efficient and quick heating of any targeted area, especially when heating metals.
Key Features:
- 100% load design, allowing continuous operation for 24 hours without stopping
- Infrared temperature detector to alarm operator in case of overheating
- Easy temperature control and simplified manual operation
Specifications:
- Input Voltage: Single Phase; 220 V or 110V
- Max. Inductive Power: 15 KW
- Max. Input Power: 7 KW
- Fluctuating Frequency: 30-80 KHz
- Output Current: 200-600 A
- Max. Heating Temperature: 1200℃ (2192℉)
Applications:
- Brazing
- Diathermy
- Sealing
- Hardening
- Annealing
- Soldering
- Smelting
Packing List:
- 1 x Induction Heater
- 1 x Foot pedal
- 3 x Fuse
Model Comparison:
Model | Max. Inductive Power | Max. Input Power | Output Current |
---|---|---|---|
USS-HFIH00001 | 15 KW | 7 KW | 200-600 A |
USS-HFIH00011 | 25 KW | 16 KW | 200-1400 A |
Product Descriptions:
- The length of the coil that can be heated is about 1 meter, which is used to heat relatively small metal parts.
- The 220V version can be used with a water cooler.
- The length of the coil that can be heated reaches 2-2.8 meters, which can be used to smelt 2kg copper.
