Compact 1/4" Zinc-Alloy 12V DC Solenoid Valve with NBR Seal

$16.99
In stock
SKU
JFZSV00007

Top-Quality Zinc-Alloy Solenoid Valves

Our team utilizes the latest technologies to offer high-quality valves at affordable prices. Explore our USS-ZSV Series Zinc-alloy Solenoid Valves, designed to excel in various applications.

  • Pipe Size: 1/4"
  • Flow Aperture: 2.5 mm
  • Body Material: Zinc Alloy
  • Gasket / Diaphragm / Seal: NBR
  • Operation Type: Direct Lift Valve
  • Operation Mode: Normally Closed
  • Voltage: DC 12V
  • Power Rating: 20 W
  • Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
  • Operational Pressure Range: Air/Water: 0-8 Bar (0 to 116 PSI); Oil: 0-5 Bar (0 to 72 PSI)
  • Flow Value: 0.23 Cv
  • Temperature, Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
  • Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)
  • OVERHEATING WARNING: Not designed for continuous operation(not a 100% duty cycle). The solenoid valve will get hot during normal use, with the coil reaching a maximum temperature of about 176°F (80℃), complying with national standard: JB/T7352-2010. Continuous energization exceeding 8 hours may cause the coil to burn.
