Zinc-Alloy 1/4" Solenoid Valve with 24V DC, NBR Seal

Our company specializes in creating high-quality valves using advanced technologies, all at a competitive price point. Introducing the ZSV Series Zinc-alloy Solenoid Valves, designed to meet your needs in various applications.

The ZSV solenoid valves are constructed with a durable zinc alloy valve body, providing optimal pressure resistance while being cost-effective compared to brass or stainless steel options.

Specifications:

• Pipe Size: 1/4"
• Flow Aperture: 2.5 mm
• Body Material: Zinc Alloy
• Gasket / Diaphragm / Seal: NBRO
• Operation Type: Direct Lift Valve
• Operation Mode: Normally Closed
• Voltage: DC 24V
• Power Rating: 20 W
• Suitable Media: Water, oil, Diesel fuel, kerosene, etc.
• Operational Pressure Range:
  • Air/Water: 0-8 Bar (0 to 116 PSI)
  • Oil: 0-5 Bar (0 to 72 PSI)
• Flow Value: 0.23 Cv
• Temperature, Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
• Temperature Maximum: 176 degrees Fahrenheit (80 degrees Celsius)

OVERHEATING WARNING: These solenoid valves are not designed for continuous operation (not a 100% duty cycle). During normal use, the coil may reach a maximum temperature of around 176°F (80℃), complying fully with the national standard JB/T7352-2010. Continuous energization for more than 8 hours may result in coil burnout.
