4V210-08 2 Position 5 Way 3 Pneumatic Solenoid Valves Manifold Base, DC 12V

$28.95
In stock
SKU
JFPSV01001

This is a 4V210-08 3 Pneumatic Solenoid Valves 2 Position 5 Way Manifold Base. This product integrates 3 pneumatic solenoid valves with a manifold base, serving as a switch for directing air to pneumatic devices. It enables a small signal to control larger devices and acts as an interface between electronic controllers and pneumatic systems.

Constructed with an aluminum alloy and featuring a 1/4" aperture, these valves allow for pneumatic control of position, flow, pressure, and temperature. Widely used in various industries, pneumatic valves play a crucial role in applications such as Pneumatic Artificial Muscles (PAM) in robotics and conveyer belt systems in manufacturing.

These pneumatic valves offer reliability, low power consumption, and long lifespan. They come with prewired connections for easy installation, maintenance, and control. Specifications include: Model: 4V210-08, Valve Type: 2 position 5 way, 3 valves, Voltage: DC 12V, Base Diameter: 8mm, Valve Diameter: 6mm, Thread Type: NPT, Operation/Property: Normally Closed, Material: Aluminum Alloy, Size: 1/4", Applicable Media: Filtered Air, Insulation & Protection: Class F; IP 65, Working Pressure: 0.15 ~ 0.8 Mpa, Max. Pressure Resistance: 1.2 Mpa, Direct Operated/Pilot Operated: Pilot Acting, Operation Temperature: -5℃ - 50℃
