4V210-08 2 Position 5 Way 6 Pneumatic Solenoid Valves Manifold Base, DC 12V

$52.95
In stock
SKU
JFPSV01005
Pneumatic Solenoid Valves

4V210-08 6 Pneumatic Solenoid Valves 2 Position 5 Way Manifold Base

This product is an integration of 6 pneumatic solenoid valves and a manifold base. It serves as a switch for air routing to pneumatic devices, enabling small signals to control large devices. It acts as the interface between electronic controllers and pneumatic systems. The valves are constructed with an aluminum alloy and have a 1/4" aperture.

These valves facilitate pneumatic control of position, flow, pressure, and temperature, making them versatile for various industries. They are commonly used in Pneumatic Artificial Muscles (PAM) for robotics and automation, as well as in conveyor belt systems in manufacturing.

These pneumatic valves are known for their reliability, low power consumption, and long lifespan. They come with prewired connections for easy installation, maintenance, and control.

Specifications:

  • Model: 4V210-08
  • Valve Type: 2 position 5 way, 6 valves
  • Voltage: DC 12V
  • Base Diameter: 8mm
  • Valve Diameter: 6mm
  • Thread Type: NPT
  • Operation/ Property: Normally Closed
  • Material: Aluminum Alloy
  • Size: 1/4"
  • Applicable Media: Filtered Air
  • Insulation & Protection: Class F; IP 65
  • Working Pressure: 0.15 ~ 0.8 Mpa
  • Max. Pressure Resistance: 1.2 Mpa
  • Direct Operated/ Pilot Operated: Pilot Acting
  • Operation Temperature: -5℃ - 50℃
