4V210-08 2 Position 5 Way 8 Pneumatic Solenoid Valves Manifold Base, DC 12V
This is a 4V210-08 8 Pneumatic Solenoid Valves 2 Position 5 Way Manifold Base. This product integrates 8 pneumatic solenoid valves with a manifold base, serving as a switch to direct air to various pneumatic devices. It enables a small signal to control larger devices, acting as a bridge between electronic controllers and pneumatic systems.
Constructed with an aluminum alloy, these valves have a 1/4” aperture and allow for pneumatic control of position, flow, pressure, and temperature. Widely utilized in different industries, pneumatic valves are commonly found in applications such as Pneumatic Artificial Muscles (PAM) for robotics and automation, as well as in conveyor belt systems in manufacturing companies.
These pneumatic valves are known for their reliability, low power consumption, and long lifespan. With prewired connections, they facilitate easy installation, maintenance, and control. The specifications for this product include: Model: 4V210-08, Valve Type: 2 position 5 way, 8 valves, Voltage: DC 12V, Base Diameter: 8mm, Valve Diameter: 6mm, Thread Type: NPT, Operation/ Property: Normally Closed, Material: Aluminum Alloy, Size: 1/4", Applicable Media: Filtered Air, Insulation & Protection: Class F; IP 65, Working Pressure: 0.15 ~ 0.8 Mpa, Max. Pressure Resistance: 1.2 Mpa, Direct Operated/ Pilot Operated: Pilot Acting, Operation Temperature: -5℃ - 50℃
