4V210-08 2 Position 5 Way 4 Pneumatic Solenoid Valves Manifold Base, DC 24V

$35.95
In stock
SKU
JFPSV01004

This is a 4V210-08 4 Pneumatic Solenoid Valves 2 Position 5 Way Manifold Base. It combines 4 pneumatic solenoid valves with a manifold base, serving as a switch to direct air to pneumatic devices. This allows small signals to control larger devices and acts as the interface between electronic controllers and pneumatic systems. The valves are constructed with aluminum alloy and have a 1/4” aperture, enabling pneumatic control of position, flow, pressure, and temperature.

Pneumatic valves are widely used in various industries, including in Pneumatic Artificial Muscles (PAM) for robotics and automation, as well as in conveyor belt systems in manufacturing companies. These valves are known for their reliability, low power consumption, and long lifespan. They come with prewired connections for easy installation, maintenance, and control.

Specifications:

  • Model: 4V210-08
  • Valve Type: 2 position 5 way, 4 valves
  • Voltage: DC 24V
  • Base Diameter: 8mm
  • Valve Diameter: 6mm
  • Thread Type: NPT
  • Operation/ Property: Normally Closed
  • Material: Aluminum Alloy
  • Size: 1/4"
  • Applicable Media: Filtered Air
  • Insulation & Protection: Class F; IP 65
  • Working Pressure: 0.15 ~ 0.8 Mpa
  • Max. Pressure Resistance: 1.2 Mpa
  • Direct Operated/ Pilot Operated: Pilot Acting
  • Operation Temperature: -5°C - 50°C
