Pneumatic Solenoid Valves Manifold Base, 2 Position 5 Way, DC 24V, 4V210-08

This is a pneumatic solenoid valve with a 2 position 5 way manifold base. It combines 6 pneumatic solenoid valves along with a manifold base, functioning as a switch to direct air to pneumatic devices. This setup enables a small signal to control large devices and serves as the interface between electronic controllers and pneumatic systems. These valves are constructed from aluminum alloy and feature a 1/4" aperture, allowing for pneumatic control of position, flow, pressure, and temperature.

Pneumatic valves like these find applications in a variety of industries, such as robotics and automation where they are used in Pneumatic Artificial Muscles (PAM). Manufacturing facilities that operate conveyor belt systems also employ pneumatic valves. These pneumatic valves are known for their reliability, low power consumption, and long lifespan. They come with prewired connections for easy installation, maintenance, and control.

Specifications:
Model: 4V210-08
Valve Type: 2 position 5 way, 6 valves
Voltage: DC 24V
Base Diameter: 8mm
Valve Diameter: 6mm
Thread Type: NPT
Operation/ Property: Normally Closed
Material: Aluminum Alloy
Size: 1/4"
Applicable Media: Filtered Air
Insulation & Protection: Class F; IP 65
Working Pressure: 0.15 ~ 0.8 Mpa
Max. Pressure Resistance: 1.2 Mpa
Direct Operated/ Pilot Operated: Pilot Acting
Operation Temperature: -5℃ - 50℃
