Motorized Brass Ball Valve- 1/2" Electrical Valve with Full Port, 85-265 V AC, 2 Wire Auto Return

$19.95
In stock
SKU
JFMSV00049

Motorized ball valves play a crucial role in a wide range of applications. This stainless steel model with a 1/2” size can open and close in just 6-8 seconds, and it stays in its new position without consuming any additional energy. This sets motorized ball valves apart from many solenoid valves, as most solenoid valves remain energized continuously when in a new position. Motorized ball valves only use energy when transitioning between open and close states. These valves are commonly integrated into home automation systems and can serve as emergency backups for water systems. They are popular among home brewers nationwide. These motorized ball valves feature top-notch construction quality and are highly cost-effective.

Specifications:

  • Valve Material: Brass
  • Ball Seat: PTFE
  • Seal: EPDM
  • Operating Time: 3-5 Seconds
  • Working Voltage: 85-265 V AC
  • Max Power: 2 W
  • Max Torque: 2 N m
  • Max Medium Pressure: 1.0 Mpa
  • Temperature Range for Flow Medium: 0°C to 100°C
  • Ambient Temperature Range: -5°C to 40°C
  • Enclosure Rating: IP65
  • Life Expectancy: 80,000 to 100,000 Cycles
  • Bore Type: Full
  • Thread Type: NPT
  • Wiring Type: 2 Wire Auto Return
